Sony ECM77B-TA5F-ACC* Mic Lavalier Electret Omni-Directional High Performance With TA5F Connector

Our Item# ECM77B-TA5F-ACC
Sony
Mfr# ECM77B-TA5F-ACC*
Mic, Lavalier, Electret, Omni-Directional, High Performance, With TA5F Connector Wired For Lectrosonics Transmitters, Includes Tie Bar & Windscreen
List Price $386.25
Our Price $362.00
Available to Order Ships in ~6-9 business days
Choose Compatible Wireless Transmitter Series: Servo Bias Input Only (Entire SM Series, UM400A) or Universal for Both Servo Bias Input (Entire SM Series, UM400A) & Older Model Lectros (M185 M187 UM190 UM195 UM200 UM400)

Product Notes

Sony ECM77B-TA5F
  • Ultra Miniature, OmniDirectional Electret Condenser Lavaliere
  • Inconspicuous Design For Film And TV Production
  • Also Works Well For Musical Recording Of Violins & Violas
  • High Performance, Extended 40-20, 000 Hz Frequency Response
  • Windscreen & Tie Bar Included
  • 1 Year Warranty On Mic Head Through Sony.  90 Days On Connector.

Perfect For Television Applications, Sony's ECM77B Omni-Directional Electret Condenser Microphone Is A Miniature Lavalier Microphone Designed To Be Inconspicuous.

Specifications:
• Black Finish
• Capsule Type: Electret Condenser
• Frequency Response: 40-20000 Hz
• Directivity: Omni
• Size (Mic Head):  5.6 X 12.5mm (1/4 X 1/2"), 1.5g (0.04 Oz)
• Output Connector: 5pin Mini XLR Connector (TA5F)
• Sensitivity (0db=1v/Pa, At 1khz): -52.0db ±2Db
• Output Impedance At 1 Khz: 150ohms (Balanced)
• Dynamic Range: Equal To Or Greater Than 90db
• Signal To Noise Ratio (A Weighted, 1khz, 1pa.): Equal To Or Greater Than 64db
• Wind Noise (W/Wind Screen): Equal To Or Less Than 40db Spl
• Maximum Input Sound Pressure Level: Equal To Or Greater Than 120db Spl


Output Connector: 5pin Mini TA Type XLR (TA5F)
Cable Length: ~46 inches

*** Power Supply Not Included ***
